Multi-function digital color plate making machine
one-step process machine is you best choice to update and upgrade
You get AP332 high-grade multifunctional digital plate makin machine means you not only get a long life black-white plate machine but also get a strenthening color print copier and printer at one time , which improve
the quality of black-white plating and bring you new buisness as well (e.g. short version color printing, film making, sampling, bid document cover, business card, box packing and so on), then bring you new profit growth.
AP3320B multifunctional color plate machine can make your plain offset printer become into color one( electronically automatic color division, print red, blue, yellow, black, color plate) it cost you less than RMB10 to make 1 set of color plate by using 4-color machine or plain offset printer, meanwhile , it open up precedent of low ost but fast color printing.
The cost of AP332 is equal to black and white but its life is 3-5 times that of ordinary plate making
machine , just like you get a set of color strengthening printer and coper without money, and its
quality and configure is greatly better than that of plain plate machine (high blackness, high
resolution ratio, big internal memory, PCL included). High price ratio, low composite lost. It is
your best choice to improve printing quality, increase your competitiveness with rivals .
Uniquely advanced color strengthening function (enhance contrast and color saturation) makes color becoming gorgeous.
Also user who do not need plate function still can enjoy high quality color copy effect which an ordinary color
machine can not compare with.
| Key Features |
| Color Copy |
polyester plate |
| color copy, print, scan and plate |
hight inteligibility , not easy stretched to deform, low cost,
high speed, long life printing sheet ( 2 times long life than
PS plate) |
| Black Addition Design |
color strenthening |
|
greatly improve blackness of duplicate,
lower edge effect, make parchment paper plating,
film, picture more plating more viligible |
make compensation to color lost, color cast and color
shortage, increase color saturation, make picture more
gorgeous (only for AP332A/AP332B) |
| Color plate |
on the version |
|
automaticly and electronicly color-division , poyler plate, black, red, yellow,
blue can be printed and plated, directly proceed
overprint in 4-color offset printer or single color offset printer.( only for AP330B) |
place the manuscript on the copy table with the version
template with scale,turn on version light, the text appear
on the its backside, and adjust the position of manuscript
according to the scale so that it is more accurate and
convenient to version work
|
| Ash bottom prevented design |
Imaging supported |
|
with noncycling toner structure, completely
solve the bottom ash problem because of waste
toner and paper scraps |
All image layout software and remote network print
supported by PCL print card, solve thoroughly
incompatible problem because using FangZheng
typesetting system for ordinary plate machine |
Main function
| mode |
AP332 black addition type
(black and white plate, colored copy) |
AP332A color strenthened type
(black and white plate, color copy) |
AP332B color plate type
(color plate and color copy) |
|
| black addition |
switch available, increase 50% blackness |
switch available, increase 50% blackness |
multiple -gear switch, increase 30-50% blackness |
|
color
enhancement |
___ |
4 -color independent choice, increase
30%color saturation |
4color independent multiple gear
choice, increase 30%-70% color saturation |
| on the version |
___ |
___ |
version template included |
| copy |
black and white, colored |
black and white, color |
black and white, colored |
| plate |
black and white plate |
black and white plate |
4- color plate |
Main specifications
| manuscript size |
maximum A3 (copy) / A3+ (print) (width:297mm +14.1mm)( length: 420mm+37.2mm ) |
resolution ratio |
1200dpi x 1200dpi (compatible)
color gradation 256, |
| plate paper size |
maximum:332mm wide:460mm long (horizontal) |
internal memory |
576MB 1,088MB (options) |
| available paper |
zinc oxide plate paper, water soluable paper, polyester paper,
chrome paper,plain paper, alabaster paper, parchment paper,
white board paper for package box use, film film |
preheat |
within 40s |
| copy speed |
20 sheets/ minute (A4 horizontal) |
| copy speed |
20 sheets/ minute (A4 horizontal) |
| zoom |
25-400% (0.1% increment) |
| accessory |
1 bottle of correction fluid for water soluble plate,
10 sheets of double side polyester paper
(only for AP332B) |
| thickned paper |
500g/m2 instead of 200g/m2 after thickning |
options |
working table, network print, fax kit, |
| gripe edge |
maximum: 4.2mm from top side |
volume |
620 x 688 x 648mm |
| scan |
|
weight |
about 68kg |
| color scan, network scan |
power consumption |
AC220-240V 800W |
| Specifications and configuration of AP330 series |
| mode |
AP332 (black and white plate, color copy) |
AP332A(black and white plate, color strengthening copy) |
AP332B(color plate and color copy) |
| function |
black and white plate,color copy , print, scan |
black and white plate,color copy , print, scan |
black and white plate,color copy , print, scan |
| plate |
black and white plate |
black and white plate |
black and white plate and color plate |
| black additon |
------- |
switch avialable |
switch avialable |
| color enhancement |
------- |
4-color enhancement and compensation (4-color switch available) |
4-color enhancement and compensation (4-color switch available) |
| color plate |
------- |
------- |
4-color plate( electronic and automatic color division |
| ash bottom prevented |
waste toner system built in, prevent bottom from becoming ash |
waste toner system built in, prevent bottom from becoming ash |
waste toner system built in, prevent bottom from becoming ash |
| gripe edge |
paper head adjustment :4.2mm (maximum) |
paper head adjustment :4.2mm (maximum) |
paper head adjustment :4.2mm (maximum) |
| switch |
directly plate and copy ,no need to switch |
directly plate and copy ,no need to switch |
directly plate and copy ,no need to switch |
| fixation |
direct fixation, self heat pressing for solid version |
direct fixation, self heat pressing for solid version |
direct fixation, self heat pressing for solid version |
| retouch |
scan into e-document or using correction liquid for retouch |
scan into e-document or using correction liquid for retouch |
scan into e-document or using correction liquid for retouch |
| mirror image |
mirror image function included, all software compatible |
mirror image function included, all software supported |
mirror image function included, all software supported |
| net card |
included |
included |
included |
| copy |
black and white copy & print |
color copy & print |
color copy & print |
| scan |
color scan |
color scan |
color scan |
| print |
PCL、SP included |
PCL、SP included |
PCL、SP included |
| resolution ratio |
600-1200dpi |
600-1200dpi |
600-1200dpi |
| on the version |
version light switch available |
version light switch available |
version light switch available |
| network print |
buy on your selection |
standard configuration |
standard configuration |
| application paper |
zinc oxide plate paper、water soluable paper、polyester paper、parchment paper 、alabaster paper 、chrome paper、film film |
zinc oxide plate paper、water soluable paper、polyester paper、parchment paper 、alabaster paper 、chrome paper、film film |
zinc oxide plate paper、water soluable paper、polyester paper、parchment paper 、alabaster paper 、chrome paper、film film |
| plate paper size |
length: 460mm width: 300mm (horizontal) |
length:460mm width：332mm(horizontal) |
length:460mm width：332mm(horizontal) |
| paper thickness |
60-500g/m2 |
60-500g/m2 |
60-500g/m2 |
| internal memory |
576MB (inlcuded)1,088MB(options) |
576MB (inlcuded)1,088MB(options) |
576MB (inlcuded)1,088MB(options) |
| speed |
21sheets/minute（A4 horizontal） |
21sheets/minute（A4 horizontal） |
21sheets/minute（A4 horizontal） |
| preheat |
within 30s |
within 30s |
within 30s |
| zoom |
25～400%(1% unit) |
25～400%(1% unit) |
25～400%(1% unit) |
| volume |
620×688×648mm |
620×688×648mm |
620×688×648mm |
| weight |
约68kg |
约68kg |
约68kg |
| power consumption |
AC220-240V 1.25kW |
AC220-240V1.25kW |
AC220-240V1.25kW | |
