AP330B/AP330B+ (Multi-function digital plate making machine)
AP330C is a new-style and upgrade machine with longevity and high resolution ratio (600dpi-1200dpi) and can proceed professional printing & network printing, color scanning, self imaging and black added plating, meantime which employ bottom-ash prevented design and can accept thickened paper(500g) and widened paper(maximum :332mm) for plating. This machine can process direct fixation without using solid version machine & baker and can extend & update copy function, high quality plating effect can compare with PS plate.
AP330B is the best choice for you to upgrade machine.
Key Features
Black addition function
Greatly increase the duplicate blackness and decrease edge effect, make parchment paper, film, colored picture plating more legible.
Ash-bottom prevented design
Toner supply system is builted with noncyclical toner structure, which can completely solve the ash bottom problem caused by wastepaper and prolong materials service time.
Paper widened function
Improve the width of plain paper from 295mm into 332mm, no edge mark and more suitable for printing plate
Image typesetting
All image layout software and remote network print supported, solve thoroughly incompatible problem because using FangZheng typesetting system.
common plate efect after extra black plate effect
layer effect from top upgrade AP330B
layer effect from commom plate machine
Main Function |
mode |
AP330B |
AP330B+ |
imaging |
yes |
yes |
plate paper widness |
332mm (maxmum) |
332mm (maxmum) |
plate paer thickness |
200g/m2 -500g/m2 |
200g/m2 -500g/m2 |
ash bottom prevent |
prevent ash from bottom because of no recycling waste toner |
prevent ash from bottom because of no recycling waste toner |
fixation |
direct fixation |
direct fixation, you can proceed fixation by solid version machine after retouching |
retouching |
retouch by corrction fluid |
retouch by corrction fluid , directly cleaning |
black addition |
yes |
click the switch, increase 50% blackness |
reference price |
RMB11000 |
RMB11800 |
Specifications |
manuscript size |
maxmum A3 for copy , maxmum A3+ for print (width 297mm +14.1mm)(length 420mm+37.2mm) |
resolution ratio |
1200dpi*1200dpi compatible, color gradation 256 |
plate paper size |
maxmum: width 332mm, length 460mm(horizantal) |
memory capacity |
576MB 1088MB(option) |
applicable paper |
zinc oxide plate paper, water soluble paper , polyester paper, chrome paper,
plain paper, business card paper, parchment paper, film (recommend polyester paper for color plate use) |
preheating time |
within 40s |
thickening paper |
200g/m2-500g/m2 |
zoom ratio |
25-400% (0.1% increment) |
paper capacity |
copy paper :350 sheets(250sheets in paper tray + 100sheets in hand feeding box) |
accessory |
1 bottle of correction fluid each for water soluable plate and polyester plate, 10 sheets of polyester paper (80 thousands of printing sheets) |
gripper edge |
maxmum 4.2mm from topside |
options |
worktable, solid version machine, fax kit, document feeder, duplexer |
print |
PCL printing , network printing,image typesetting supported |
volume weight |
volume: 620x688x648 weight:68kg |
scan |
color scan, newwork scan |
power consumption |
AC220-240V 1.25kw |
product parameter |
|
|
|
introduction for main function |
|
plate |
applicable paper:zinc oxide plate paper、water soluable paper、polyester paper、alabaster paper、parchment paper、film film |
black addition(practical function) |
Unique black addition function can greatly enhance the contrast and blackness on the layout of the whole page,
eg.when duping , through adjusting the "- density "key of control panel in common machine , the copy sheet
either be inditinct or with ash bottom problem;while, by pushing the "exta black " key on plate making machine,
the text of copy not only can be hanced in blackness and sharpness but also ash bottom prevented and no hollow word. |
plate/copy switch mode |
no need swicth step,directly plate and print |
retunching |
direct fixation without using solid version machine
retunching in computer after scanning into e-document |
plate paper widen/thicken |
widened paper path :320mm-330mm wide plate paper acceptable
it is avoidable for the dark edge problem caused by narrow plate
thichened plate pape:60 g/m2-500g/m2 wide plate paper and white cardboard can be passed through. |
intruodction for other functions
|
copy |
one time scan for multi copies, laser imaging,automatically paper selection,auto zoom、auto density |
print |
A set of drum kit can print more than 100 thousands of sheets, which makes cost lower than ordinary printer. |
scan |
It can scan paper sheet into e-document, thus to make office work diversification |
fax |
Equipped fax component on selection can send and receive fax whatever using plain paper or no paper thus to save your papers and long- distance telephone charge. |
network |
Long distance print can be achived though network |
mirror image |
PCL included, with mirror image print function, all layout softwares supported |
special function |
Black and white picuture reversion, watermark ,90° of image rotatioin , eliminate center joint and frame, many sheets into one sheet, IC card, electronic paging |
polyester plate |
Plate base is polyester, with aquosity on both side, both side usable. (version method:machine self-fixing or baking throuth oven )Advantage: high sharpness, no stetched and deformation, long print life, low printing cost, effect can match with PS plate |
|
Specifications and configuration for AP330B Series
|
Model |
AP330B (with extra black & ash bottom-prevented function ) |
AP330B+ (with extra black & ash bottom-prevented function ) ---simply plate |
function |
plate,copy,print,scan |
plate,print,scan |
black addition |
switch available, increase 50% blackness |
switch available, increase 50% blackness LED |
switcher |
direct plating and printing without switcher |
direct plating and printing without switcher |
control panel |
color LCD touch screen |
color LCD touch screen |
rate |
21 sheets/minute |
21 sheets/minute |
on the version |
version light switch available |
version light switch available |
fixation |
immediate fixation |
no fixing function |
retouching method |
retouch water soluble paper or polyester paper with correction liquid, or scan into e-document to retouch |
retouching by cleaning with cotton ball or scan intoe-document to retouch |
mirror image |
mirroring function included、all software supported |
mirroring function included、all software supported |
print |
PCL、SP(included) |
PCL、SP(included) |
scan |
color scan |
color scan |
newwork print |
network print software included |
network print software included |
internal memory |
576MB included |
576MB included |
resolution ratio |
600dpi-1200dpi,color gradation:256 |
600dpi-1200dpi,color gradation:256 |
ash bottom-prevention |
waste toner recycling system,prevent bottom from becoming ash |
waste toner recycling system,prevent bottom from becoming ash |
effective breadth |
A3+ |
A3+ |
gripper edge |
0-4.2mm (host settings) |
0-4.3mm (host settings) |
application paper |
zinc oxide plate paper、water soluable paper、polyester paper、chrome paper 、alabaser paper 、parchment paper、film film |
zinc oxide plate paper、water soluable paper、polyester paper、chrome paper 、alabaser paper 、parchment paper、film film |
printing paper thickness |
60-500g/m2 |
60-500g/m2 |
plate size |
330mm wide、460mm long |
330mm wide、500mm long |
plate thickness |
60-600g/m2 |
60-600g/m2 |
zoom |
25~400%(1%unit) |
25~400%(1%unit) |
options |
duplexer, document feeder |
duplexer, document feeder |
volume |
620×688×648mm |
620×688×648mm |
weight |
about 60kg |
60kg |
power consumption |
AC220-240V1.25kW |
AC220-240V1.25kW |
|
