3rd Generation plate making machine with extra black function lead plate industry to a new trend
4 Basic Functions
l Plate: zinc oxide plate paper, water soluble paper and parchment paper used for mini offset print press; color cardboard and projection film
l Copy: multiple copy at one time scan by laser imaging, automatic paper selection, automatic zoom, automatic density and so on
l Print:GDI included, less cost than profession printer
l Scan: scan paper document into e-document, diversify office work by sharing and applying data
4 Main Features
l Black addition
unique black addition design can greatly enhance the printing quality. As we know , the common digital plate making machine easily have the edge effect problem
in the character (edge black , middle shallow), while AP320III makes breakthrough accordingly by adding blackness from 1.0 to 1.6 and successfully solve this problem,
as a result you can see very legible and extra black words, as below shown
l On the version
Version template included. place original manuscript and turning on light to make the text appear on its backside, then make some adjustment according to the scale mark
on version template , which can effectively avoid relevant troubles & plate waste before printing on offset printing press in the case of skew picture and text on original manuscript,
it will be more accurate and convenient to proceed version work.
l Energy saving
For other plate making machine, the heating fixation light is still working under the mode of plating, which can cause great electricity waste at about 1kw/h. For AP320III with exclusive
energy design, we can turn off fixation heating system even though on the plating state in order to save time & electricity , prolong life of fixation parts and lower maintenance cost ,
more importantly to save you a great number of electricity fee.
l Longevity
The improvement to the developing chamber component makes its life more than twice and save user more than RMB1000 of maintenance cost
ordinary machine black addition machine
plate function and configuration |
|
|
mode |
AP320III (8 in 1, extra black) |
|
|
function |
plate, copy,scan,print,black addition,energy,longevity,on the version |
|
|
configuration |
side paper box(by hand) |
|
|
advantage |
black addition, energy saving, long life, and economic function greatly lower comprehensive service cost |
|
|
|
|
|
|
|
|
|
|
|
|
plate --specifications |
|
|
paper size |
A3, B4, maximum width:320cm length:500cm |
paper type |
zinc oxide plate paper、water soluable paper、polyester paper、parchment paper color cardboard paper |
|
|
gripper edge setting |
digital multi file location, size:0-50mm |
blackness |
1.6 |
|
|
version template |
included |
long-life developing chamber |
included |
|
|
|
|
energy |
save electricity at 1kw/h |
plate-copy switch |
one key switch |
|
|
|
|
|
|
|
|
|
|
|
|
copy--specifications |
print--specifications |
scan--specifications |
resolution ratio |
600dpi x 600dpi/256 grade |
GDI Driver |
built-in, TCP/IP |
method |
local TWAIN black and white scanning |
memory capacity |
32MB (maximum 160MB by options ) |
continious printing speed |
22sheets/min. (B5:300*300dpi) 16sheets/min. (A4:600*600dpi) |
max. manuscript size for scanning |
A3 |
manuscript type |
paper/book/3D object(no more than 3.0kg) |
resolution ratio |
150*150dpi, 300*300dpi, 600*600dpi |
size |
A3,B4,A4,A4 horizontal,B5,B5 horizontal,A5,A5 horizontal,postcard special paper size:max. 297*432mm,min.90*140mm |
resolution ratio |
300*300dpi, 600*600dpi |
interface |
USB2.0 |
paper type |
common paper, recycled paper, thick paper, OHP, postcard paper, label paper, envelop |
OS supported |
windows98//me/2000(SP14 more)/XP(SP2 more)/server2003 |
OS supported |
windows98/ME/2000/XP/Server2003 |
preheating time |
0 second |
speed |
18 sheets/minute(B5), 12 sheets/minutes(A43) |
interface |
USB2.0 |
output time for first copy |
within 7s(A4 horizontal) *manuscript table scanning and by 1st paper tray |
network print |
options: Ethernet 100 Base-TX/10Base-T |
Driver |
TWAIN |
paper thickness |
copy paper60-157g/m2, plate paper 60-500g/m2 |
continuous copy sheets |
1-99 sheets |
|
|
|
|
interface |
USB2.0 |
|
|
|
|
power |
220-240V, 5.5A (50/60Hz) |
|
|
|
|
maximum power consumption |
1.05kw |
|
|
|
|
size(length*width*height) |
599*620*520mm(include cover plate) |
|
|
|
|
area (length*width) |
599*620mm |
|
|
|
|
weight |
about 39kg |
|
|
|
|
Specifications and technical parameters for AP320III
Model |
AP320Ⅲ (with extra black function) |
function |
plate,copy,print,scan,extra black,energy saving,longevity,on the version |
extra black |
increase 50% blackness by clicking "extra black" botton |
energy saving |
power saving :about 1000w/h |
on the version |
on the version system (included),imposition can be very convenient and accurate |
longevity |
double lifetime |
preheat time |
immediate plate making under energy saving condition once starting up |
effective breadth |
effective text breadth A3 (297mm×420mm) |
fixation |
no fixation |
buy Solid version machine for fixation |
retouching method |
by cleaning with cotton ball |
or scan into e-document for correction |
switcher |
"plate and copy" key |
mirror image |
WPS、Graphics9 |
print |
GDI(included),PCL(purchase on selection) |
scan |
TWAIN / WIA |
internal memory |
32MB(included) :160MB(or equiped on selection ) |
dot per inch |
600dpi×600dpi,color gradation:256 |
printing plate size |
320mm (width)、600mm (length)(both vertical and horizontal ) |
speed |
16 sheets/minute(A4 horizontal) |
gripper edge |
0-50mm |
application paper |
zinc oxide plate paper、water soluable paper、polyester paper、chrome paper,alabaser paper,parchment paper, film film |
plate thickness |
60-500g/m2 |
zoom |
25~400%(1%unit) |
volume |
599×620×520mm |
weight |
about 39kg |
power consumption |
AC220-240V 1.05kW | |
